1 / 1KOFO water-cooledseries diesel generator sets
share
Power coverage from: 22~413KVA
Model: Open type/Silent/Super silent type
Engine: KOFO
Speed: 1500rpm
Alternator: Stamford/LeroySomer/Marathon/MeccAlte
IP&Insulation Class: IP22-23&F/H
Frequency: 50Hz
Controller: Deepsea/Comap/SmartGen/Mebay/DATAKOM/Others
ATS System: AISIKAI/YUYE/Others
Silent&Super silent Gen-set Sound level: 63-75dB(A)(at 7m side)
Technical Data
| Genset Performance | Engine Performance | Dimension(L*W*H) | ||||||||||
| Genset Model | Prime Power | Standby Power | Engine model | Speed | Prime power | Fuel Cons (100% Load) | Cylinder- Bore*Stroke | Displacement | Open Type | Silent Type | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| KW | KVA | KW | KVA | rpm | KW | L/H | No. | L | CM | CM | ||
| DAC-KF22 | 16 | 20 | 18 | 22 | 4YT23-20D | 1500 | 20 | 4.2 | 4 | 2.31 | 135*75*96 | 185*85*106 |
| DAC-KF33 | 24 | 30 | 26 | 33 | 4YT23-30D | 1500 | 30 | 6 | 4 | 2.31 | 135*75*96 | 185*85*106 |
| DAC-KF33 | 24 | 30 | 26 | 33 | N4100DS-30 | 1500 | 30 | 7.2 | 4 | 3.61 | 160*75*110 | 210*85*121 |
| DAC-KF41 | 30 | 38 | 33 | 41 | N4105DS-38 | 1500 | 38 | 8 | 4 | 4.15 | 160*75*110 | 210*85*121 |
| DAC-KF44 | 32 | 40 | 35 | 44 | N4100ZDS-42 | 1500 | 42 | 9.3 | 4 | 4.15 | 160*75*110 | 210*85*121 |
| DAC-KF66 | 48 | 60 | 53 | 66 | N4105ZDS | 1500 | 56 | 12.6 | 4 | 4.15 | 170*80*115 | 230*90*126 |
| DAC-KF80 | 58 | 73 | 64 | 80 | N4105ZLDS | 1500 | 66 | 15.2 | 4 | 4.15 | 170*85*115 | 234*95*126 |
| DAC-KF110 | 80 | 100 | 88 | 110 | 4RT55-88D | 1500 | 88 | 19.5 | 4 | 4.33 | 200*95*120 | 260*105*131 |
| DAC-KF132 | 96 | 120 | 106 | 132 | 4RT55-110D | 1500 | 110 | 24 | 6 | 5.32 | 200*95*120 | 260*105*131 |
| DAC-KF154 | 112 | 140 | 123 | 154 | 6RT80-132D | 1500 | 132 | 26.7 | 6 | 7.98 | 240*100*148 | 300*110*158 |
| DAC-KF220 | 160 | 200 | 176 | 220 | 6RT80-176DE | 1500 | 175 | 39.1 | 6 | 7.98 | 250*110*148 | 310*120*158 |
| DAC-KF275 | 200 | 250 | 220 | 275 | WT10B-231DE | 1500 | 231 | 50 | 6 | 9.73 | 290*120*170 | 350*130*180 |
| DAC-KF303 | 220 | 275 | 242 | 303 | WT10B-275DE | 1500 | 275 | 55 | 6 | 10.5 | 310*120*180 | 370*130*190 |
| DAC-KF358 | 260 | 325 | 286 | 358 | WT13B-308DE | 1500 | 308 | 65 | 6 | 11.6 | 320120*180 | 380*130*190 |
| DAC-KF413 | 300 | 375 | 330 | 413 | WT13B-330DE | 1500 | 330 | 72.6 | 6 | 12.94 | 340*130*190 | 400*140*200 |
Product Description
The KOFO water-cooled series diesel generator set, with power coverage ranging from 22 to 413KVA, these generator sets provide reliable, efficient power for a variety of applications.
Available in three different models - open, silent and ultra-quiet - you can choose the generator set that best suits your specific requirements.Our generator sets feature KOFO engines and are designed to provide exceptional performance and durability. These engines operate at 1500rpm, ensuring smooth and efficient power generation.
To ensure excellent performance, our generator sets are equipped with high-quality alternators from well-known brands such as Stanford, Leroy-Somer, Marathon and McCarter. These alternators ensure stable and consistent power output even under heavy load conditions.
Safety is our top priority, which is why our generator sets are designed with IP22-23 and F/H insulation ratings. This ensures protection against dust and water ingress, making our generator sets suitable for use in a variety of environments.
Our generator sets have a frequency of 50Hz and are compatible with a variety of electrical installations and equipment.They are also equipped with advanced controllers from well-known brands such as Deepsea, Comap, SmartGen, Mebay, DATAKOM and more. These controllers provide precise monitoring and control of generator set performance, making operation and maintenance easier.
For added convenience, our generator sets are equipped with an ATS (Automatic Transfer Switch) system. Offered by trusted brands such as AISIKAI and YUYE, this system enables automatic switching between mains and generator power, ensuring uninterrupted power supply.
Our Silent and Ultra Silent generator set models are designed for quiet operation, with sound levels ranging from 63 to 75dB(A) at a distance of 7m. This makes them ideal for use in noise-sensitive environments, such as residential areas or hospitals, where noise pollution must be kept to a minimum.
